45W (TUV-CE) LED Driver

▶ Voltage Design,200-240V
▶ Plastic shell,IP20
▶ 100% Full Load Burn-in Test
▶ Certificate:TUV CE UKCA CB RCM ROHS
▶ Over Power/Short Circuit/ Over Voltage/Over Temp Protection

Inquire Online

PRODUCT INFORMATION

▶ Voltage Design,200-240V

▶ Plastic shell,IP20

▶ 100% Full Load Burn-in Test

▶ Certificate:TUV CE UKCA CB RCM ROHS

▶ Over Power/Short Circuit/ Over Voltage/Over Temp Protection

Application

Parameters

Model No:		ND-D12045A	ND-D24045A
Output	Rated Output Voltge	12V	24V
	Output Current Range	0-3.75A	0-1.875A
	Rated Output Power	45W	45W
Input	Input Voltage Range	200-240V	200-240V
	Input Frequency Range	50-60HZ	50-60HZ
	Power Efficency	>85%	>87%
Szie(mm)		1856322	1856322
